The BoxLambda SoC Component

The BoxLambda SoC module itself is defined as a gateware component.

/*The parameterized BoxLambda SoC.*/
module boxlambda_soc #(
    parameter DPRAM_BYTE_ADDR_MASK = 'h1ffff, /*DPRAM size as a mask value. Used both from CMEM and DMEM.*/
    parameter VRAM_SIZE_BYTES = 131072,
    parameter DEBUG_MODULE_ACTIVE = 1,
    parameter DRAM_ACTIVE = 1,
    parameter VERA_ACTIVE = 1,
    parameter SDSPI_ACTIVE = 1,
    parameter YM2149_ACTIVE = 1,
    parameter PICORV_ACTIVE = 1,
    parameter USB_HID_ACTIVE = 1,
    parameter SPIFLASH_ACTIVE = 1,
    parameter CMEM_FILE = "",
    parameter DMEM_FILE = ""
) (
    input wire ext_clk_100,  //100MHz external clock.
    input wire ext_rst_n,    //External reset pin.

`ifdef VERILATOR
    /*These JTAG signals are not used on FPGA (they are used in simulation).
   *On FPGA, the JTAG signals are driven by a BSCANE2 primitive inside the jtag tap module dmi_bscane_tap.sv.
   */
    input  wire        tck,
    input  wire        trst_n,
    input  wire        tms,
    input  wire        tdi,
    output wire        tdo,
`endif
    output wire        pll_locked_led,      //PLL locked indication.
    output wire        init_done_led,       //LiteDRAM initialization done indication.
    output wire        init_err_led,        //LiteDRAM initialization error indication.
`ifdef SYNTHESIS
    /*The simulation build doesn't export DDR pins.*/
    output wire [13:0] ddram_a,
    output wire [ 2:0] ddram_ba,
    output wire        ddram_ras_n,
    output wire        ddram_cas_n,
    output wire        ddram_we_n,
    output wire        ddram_cs_n,
    output wire [ 1:0] ddram_dm,
    inout  wire [15:0] ddram_dq,
    inout  wire [ 1:0] ddram_dqs_p,
    inout  wire [ 1:0] ddram_dqs_n,
    output wire        ddram_clk_p,
    output wire        ddram_clk_n,
    output wire        ddram_cke,
    output wire        ddram_odt,
    output wire        ddram_reset_n,
`endif
    // VGA interface
    output wire [ 3:0] vga_r,
    output wire [ 3:0] vga_g,
    output wire [ 3:0] vga_b,
    output wire        vga_hsync,
    output wire        vga_vsync,
    // SDSPI interface
    output wire        sdspi_cs_n,
    output wire        sdspi_sck,
    output wire        sdspi_mosi,
    input  wire        sdspi_miso,
    input  wire        sdspi_card_detect_n,

    // Flash SPI interface
    output wire spiflash_sck,
    output wire spiflash_cs_n,
    output wire spiflash_mosi,
    input  wire spiflash_miso,

    // USB HID, two ports.
    input  wire usb0_dm_i,
    input  wire usb0_dp_i,
    output wire usb0_dm_o,
    output wire usb0_dp_o,
    output wire usb0_oe,
    input  wire usb1_dm_i,
    input  wire usb1_dp_i,
    output wire usb1_dm_o,
    output wire usb1_dp_o,
    output wire usb1_oe,

    // Audio interface
    output wire        audio_out,
    output wire        audio_gain,
    output wire        audio_shutdown_n,
`ifdef VERILATOR
    // Audio interface signals only used in simulation
    output wire [15:0] pcm_out,
    output wire        acc1_overflow,
    output wire        acc2_overflow,
`endif
    // UART and GPIO
    input  wire        uart_rx,
    output wire        uart_tx,
    inout  wire [ 7:0] gpio0,
    inout  wire [ 3:0] gpio1
);

The Gateware Build Structure section describes the three-layer gateware build structure. The diagram below shows how the BoxLambda SoC component fits in that build structure.

BoxLambda SoC Component Build Diagram.

Build Diagram with BoxLambda SoC component and boxlambda_top.sv.

Different gw/project/ builds reference this boxlambda_soc component. The project builds differ in the way they instantiate the boxlambda_soc module, including or excluding specific subcomponents. Most gw/projects reference the same boxlambda_top.sv module but with a different combination of defines in their Bender.yml manifest.

Gw/project/ builds also differ in the software program they run on the SoC. This is specified in the gw/project/'s CMakefile.
